11.44 Kwh Wall Mounted Battery Storage System For Residential House

Product Categories

Jiangsu GXY new energy co.,Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Name: 1144 Kwh Wall Mounted Battery Storage System For Residential House
Brand: Solarsonc
Price: 2200 USD

Brand Name : Solarsonc

Model Number : BG-1144

Certification : TUV/UN38.3/IEC

Place of Origin : JIANGSU

MOQ : 1

Price : USD2200-3000/SET

Payment Terms : L/C, T/T, Western Union, MoneyGram

Supply Ability : 500 SET PER MONTH

Delivery Time : 20-30 working days

Packaging Details : wooden box/carton

Battery Capacity : 11.44 kWh

Battery Chemistry : Lithium-ion

Communication Protocol : Wi-Fi/Ethernet

Dimensions : 1000mm x 500mm x 200mm

Installation Type : Wall Mounted

Maximum Charge/Discharge Current : 100A

Maximum Charge/Discharge Power : 10kW

Maximum Voltage : 400V

Operating Humidity : 0-90% RH

Operating Temperature : 0-50°C

Product Name : Wall Mounted Battery Storage

Remote Monitoring : Yes

Safety Certifications : CE, FCC

Warranty : 5 Years

Weight : 50kg

Contact Now

Cell Technology	LiFePo4 Cylindrical Full Tabs Cell
Rated Capacity(KWh)	5.12	8.58	11.44
Usable Capacity(KWh)	5.43	8.15	10.87
Nominal Voltage(V)	51.2V
Operating Voltage(V)	40-57.6V
Dimensions(WHD)(mm/inch)	6202551087 27.1710.0442.8
Weight(kg/Lb)	116/255.74	134/295.42	152/335.1
Recommend Discharge Current(A)	100
Peak Discharge Current(A)	200	300	400
Battery Pack Round-Trip Effificiency	>95%
Depth of Discharge	90%
Cycle Life	≥6000 cycles,(25°C/77°F/DOD 90%)
Warranty	10 years
Communication	CAN
Scalability	Max.4 Modules in Parallel
Certificates	CE/IEC62619/UN38.3
Cell Certificate	UL 1642
OPERATING CONDITIONS
Operating Temperature(°C/°F)	-20℃~45℃/-4°F~113°F
Storage Temperature(°C/°F)	-10℃~45℃/14°F~113°F
Cooling Method	Natural Convection
Humidity	0%to100%(No Condensing)
Altitude(m)	Max.3000
Installation Mode	Wall mounted/Floor mounted
Ip Level	IP65

11.44 Kwh Wall Mounted Battery Storage System For Residential House
